SPECIFICATIONS

Brand Name: YTBNA

Certification: CE

Choice: yes

Connector model: JST PH 2.0

Model Number: 503450

Nominal Capacity: 1000mAh

Origin: Mainland China

Set Type: Batteries Only

Size: 5*34*50mm

Type: Lithium Rechargeable Battery,Li-polymer

Volt: 3.7V

semi_Choice: yes

503450/523450 3.7V 1000mAh Polymer Lithium Rechargeable Battery PH2.0 2pin For GPS Smart Phone MP5 Mobile phone, DVD,Camera


pay attention: Please note that when placing an order, 503450 and 523450 are the same model, and the battery size, capacity, voltage and other performance are exactly the same

Product Features:

1, Built-in protection circuit PCM for prevent over charging or over discharging

2,Rating: DC3.7V 1000mAh
3,Plug:jst PH 2.0mm connector
4,Size: 5mm (H)*34mm (W)*50mm (L)

5,Charging current: standard charging, fast charging: 1.0C: 0.5C

6,Standard charging method: 0.5C CC (constant current) charge to 4.25V,then CV (constant voltage 4.2V) charge till charge current is less than or equal to 0.05C.

7,Maximum discharge current: 1C
8,The maximum charge current: 1C

9,Discharge cut-off voltage: 2.75V

10,Charging time: 3-7hrs (standard); 3hrs (fast)
11,The discharge temperature: -20 degrees C~+60 degrees C

12,Protection function: over charge, over discharge, over current, short circuit protection, over temperature protection

13,Cycle charge:＞1000 times

14,Built-in protection circuit PCM for prevent over charging or over discharging.
